WATTI DIRECT COLLECTION
Direct Current Fast Charging Infrastructure for High-Demand Commercial Sites
Watti Direct DC fast chargers provide scalable, high-power EV charging solutions for commercial and fleet applications. With power configurations ranging from 40kW to 480kW — and Ultra models up to 1.6MW — the platform supports passenger EVs, commercial vans, heavy-duty trucks, and transit vehicles across a wide output voltage range.
All Watti Direct Gen2 models are Energy Star certified and support dynamic load management, OCPP integration, smart energy allocation, and optional payment systems for public monetization.
Add Enterprise Software to enable remote monitoring, user management, flexible pricing, fleet access control, and advanced network optimization across multi-charger deployments.
Watti Direct 40kW–60kW
Available in 40kW or 60kW power levels
Dual output configuration: CCS1 + NACS
Choice of 4.5m (15ft) or 7m (23ft) charging cables
7-inch high-contrast touchscreen display (daylight readable)
Connect via Ethernet (LAN), WiFi, or LTE (4G)
Supports OCPP 1.6 and OCPP 2.0.1
Supports ISO 15118-2 and DIN 70121 (ISO 15118-20 OTA update capable)
Multiple authentication options: Plug & Charge, RFID, QR code, Auto Charge (credit card payment optional)
Rugged outdoor-rated enclosure: NEMA 3S, IK10 vandal-proof, IK08 touchscreen
*Available with an Enterprise Software subscription. Pedestal and cable management sold separately.
Watti Direct Gen2
Available in 60kW, 120kW, 180kW, and 240kW
Simultaneous dual DC charging (dual CCS1, dual NACS or Combo connectors available) with up to 300A peak output. Supports Smart Charging and Dynamic Load Management.
Choice of 5m (16.4ft) or 7.5m (25ft) charging cables with built-in cable management
High-contrast 10-inch instructional touchscreen
Supports OCPP 1.6, OCPP 2.0.1, and ISO 15118 protocols
Connect via LAN, WiFi, or optional 4G
User authentication via RFID, QR Code, or Mobile App
Optional integrated payment terminal available
Real-time analytics, monthly reporting, multi-user group access controls, revenue collection and management*
*Available with an Enterprise Software subscription
Watti Direct Gen2 240–480kW High-Power DC Fast Charger
Configurable high-power output from 240kW up to 480kW
Simultaneous dual CCS charging with intelligent power sharing
Modular power architecture for scalable deployment and simplified serviceability
Supports Smart Charging and Dynamic Load Management for multi-charger sites
Wide output voltage range to support passenger EVs, commercial fleets, and heavy-duty vehicles
High-brightness LCD display with intuitive user interface
Connectivity via LAN, WiFi, or 4G for networked charging infrastructure
User authentication via RFID, App, QR Code, or Plug & Charge (ISO 15118)
Real-time analytics and automated reporting*
Advanced user group management and pricing control*
*Available with an Enterprise Software subscription
